Roof standard solar mount,Aluminium Alloy Solar Roof Mounting

Roof standard solar mount,Aluminium Alloy Solar Roof Mounting

  • Colour
    Silvery, Black, Any Color Is Available As Per Require
  • Surface Treatment
    Anodized, Powder Coating, Electrophoresis,painting...
  • Lifetime
    More Than 15 Years
  • MOQ
    10sets
  • Company Honor
    China Famous Trademark
  • Skype
    James.wang0307
  • WeChat
    Jameswang0307
  • WhatsApp/Viber/Mobile
    86 18662963676
  • QQ
    1021035269
  • Production Capability
    10000sets/month
  • OEM/ODM
    Available
  • CO,FormA, FormB, FormE...
    Available
  • Samples
    Free
  • Web1
    Http://www.profiles-aluminum.com
  • Web2
    Http://aluminum-extrusion.sell.everychina.com/
  • Materials
    Aluminum,stainless Steel
  • Wind Load
    Up To 80m/s
  • Snow Load
    Up To 2KN/m2
  • Design Standard
    AS/NZS 1170
  • E-mail
    Jameswang0307@gmail.com
  • Key Words
    Solar Mounting
  • Place of Origin
    Jiangyin, Jiangsu, China
  • Brand Name
    YueFeng
  • Certification
    ISO9001
  • Model Number
    YF-190
  • Minimum Order Quantity
    10Sets
  • Packaging Details
    EP paper + Kraft Paper + Plywood pallet, as per export packing standard, custom packing is available
  • Delivery Time
    within 16 days after received your deposits
  • Payment Terms
    50% should be paid before produce, the balance should be paid before shipment.
  • Supply Ability
    10000sets/month

Roof standard solar mount,Aluminium Alloy Solar Roof Mounting

1.Specification of aluminum pv solar rail mounting

Mount Type

pv aluminum solar rail mounting

Applicable roof cladding roof mount,ground mount,carport mounting rail
Applicable Module framed or frameless panel
Module Orientation landscape or portrati
Wind load 130mph(60m/s)
Snow load 30psf(1.4KN/m2)
Material aluminum alloy and stainless steel 304
Warranty

10years

2.Features of YUEFENG Solar rails

1).Easy Installation.

The innovative Wanhos solar rail and D-modules have greatly simplified the installation of PV modules.The System can be installed with a single Hexagon Key and standard tool kits. Pre-assembled and pre-cut processes will highly prevent corrosion and save your installation time and labor cost.


2).Great Flexbilitity.

The Wanhos solar mounting system has mounting accessories designed for use on almost every roof and ground with excellent compatibility.Designed as a universal racking system,framed modules from all the popular manufacturers can be used.

3).High Accuracy.

Without the need for onsite cutting,the use of our unique rail extending allows the system to be installed with millimetre accuracy.

4).Maximum Lifespan:

All components are made of quality extruded aluminium, C-steel and stainless steel.The high corrosion resistance guarantees the maximum possible lifespan and is also completely recyclable.



5).Guaranteed Durability:

Wanhos Solar provides a guarantee of 10 years on the durability of all components used.



If you want to know about more information, please contact us or call me 0086 18662963676 (Urgent things), weblink:http://www.profiles-aluminum.comaluminum-extrusion.sell.everychina.com.

Brief Installation Plan for corrugated tin roof solar mounting system

Roof standard solar mount,Aluminium Alloy Solar Roof Mounting 0































1,L-feet group installation
  1),Mark the installation position
  2),Bolt L-feet to the rafter

2,Rail installation
  1),Slide the G-module into the rail and fasten it in the right position
  2),Install the rail on the L-feet with G-module
3,Pv panel Installation

Roof standard solar mount,Aluminium Alloy Solar Roof Mounting 1































The Specification of PV Mounting Tin Roof Structure ,



ST Solar Tin Roof Hook System

Optional Size

Mid Clamp

35-50 mm

End Clamp

35-50 mm

 Roof Hook

For kinds of Metal Roof types



Roof standard solar mount,Aluminium Alloy Solar Roof Mounting 2





























Roof standard solar mount,Aluminium Alloy Solar Roof Mounting 3





























Roof standard solar mount,Aluminium Alloy Solar Roof Mounting 4





























Roof standard solar mount,Aluminium Alloy Solar Roof Mounting 5





























Steel Ground Screw Anchor:

The Metal Ground Screw has been widely used in the conctruction of the Solar Power Plant from these years, for its

easily installation and the perfect perform in anti-corrosion wear-proof. With such metal ground screws, installtion

could be realized in so many kinds of places, such as those not so even ground or the ground with slopes, which will

largely reduce the cost for the plant construction. YUEFENG metal Ground Screw has been focusing on customising any

length and other requirements of the customer.



Technical Information:

Installation Sites: OPen Ground
Foundation Solustions: Concrete Foundation/ Steel Foundation
Main Materials: Steel Tube Q235B
Finishing: Hot-dip Galvanized
Fasteners Materials: Stainless Steel SUS304
Diameter: Φ76mm
Tube Thickness: 4mm
Length: 1000-2000mm
Finishing Thickness: ≥80µm
G.W/PCS 10-15kg
Loading/40'GP 1600-2200pcs
Packing: Steel Pallet with film PVC
Design Standards: JIS C 8955:2011; AS/NZS 1170; DIN 1055; IBC 2009
Warranty: 20-25 years life span

Roof standard solar mount,Aluminium Alloy Solar Roof Mounting 6





























FAQ

Reasons to choose YUEFENG mounting system ,

  • Design conformable to different project requirements
  • Fast and cost effective installation, easy to be assembled on different area.
  • Short in 7-30 days leading time according to acrtual quantities
  • Wisely solutions for your solar PV projects



Which Datas need provide when inquiry,

-----------



Dear Buyer,

In order to help you get the right system, please offer the following necessary info.,

1. The dimension of the solar panel: _________(L*W*T)

2. Tin roof photo or section: __________

3. The overall size of the PV array:____________

4. Wind load and snow load: ____________

5. The height of building:_______________

6. The order quantity for us to confirm delivery and shipping:______________



If you want to know about more information, please contact us or call me 0086 18662963676 (Urgent things), weblink:http://www.profiles-aluminum.comaluminum-extrusion.sell.everychina.com.
